INCH-POUND
W-F-1814/53C
01 October 2009 SUPERSEDING
W-F-1814/538
15 December 2003
FEDERAL SPECIFICATION SHEET
FUSE, CARTRIDGE, HIGH INTERRUPTING CAPACITY, CLASS L (CURRENT-LIMITING) 600 VOLTS, 3001-4000 AMPERES
The General Services Administration has authorized the use of this federal specification sheet by all federal agencies.
The complete requirements for procuring the fuses described herein shall consist of this document and the latest issue of Specification W-F-1814.
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerances are ±0.02 (0.51 mm) for two-place decimals and ±0.005 (0.13 mm) for three-place decimals.
4. Slots and holes shall be .62 (15.75 mm).
FIGURE 1. Configuration and dimensions.
AMSC N/A FSC 5920
