[INCH-POUND]
A-A-55471D
9 May 2012
SUPERSEDING
A-A-55471C
3 May 2007
COMMERCIAL ITEM DESCRIPTION
FUSE, PLUG, (TYPE TL),
TIME DELAY, EDISON BASE
The General Services Administration has authorized the use of this
commercial item description for all federal agencies.
1. SCOPE. This commercial item description (CID) covers the general requirements for a time delay,
type TL fuse plug. Fuse plugs covered by this CID are intended for commercial/industrial applications.
2. CLASSIFICATION/PART OR IDENTIFICATION NUMBER (PIN). This CID uses a classification
system which is included in the PIN as shown in the following example (see 7.1).
AA55471
-
01
CID PIN
Dash number
(see table I)
3. SALIENT CHARACTERISTICS.
3.1 Interface and physical dimensions. Fuse plugs supplied to this CID shall be as specified herein and
3.2. Ampere rating. The ampere rating shall be as specified in table I.
3.3 Voltage rating. The voltage rating shall be 125 V ac maximum.
3.4 Interrupt rating. The interrupt rating shall be 10,000 amperes rms at 125 volts.
3.5 Fuse plug base (screw shell). The screw shell shall be of the Edison base size in accordance with
3.6 Marking. Fuse plugs supplied to this CID shall be marked with the manufacturer's (MFR's) standard
commercial PIN and the UL 248-11 listing mark. (NOTE: The part number marked on the unit pack shall
be the CID PIN.)
Beneficial comments, recommendations, additions, deletions, clarifications, etc., and any data that may
improve this document should be sent to: DLA Land and Maritime, ATTN: VAT, P.O. Box 3990,
Columbus, OH 43218-3990, or email m ai l t o: Ci r cu i t Pr ot ect @d l a. m i l . Si n ce con t act i n f or m at i on
can ch an g e y ou m ay w an t t o v er i f y t h e cu r r en cy of t h e ad d r ess i n f or m at i on u si n g t h e
ASSI ST On l i n e d at ab ase at ht t p s: / / assi st . d ap s. d l a. m i l / .
AMSC N/A
FSC 5920
