A-A-55493D
AA55493-
Dimensions
A
B
C
001
1.500
.406
.374
through
(38.10)
(10.31)
(9.50)
006
.820
007
2.000
.813
(20.83)
through
(50.80)
(20.65)
.495
011
(12.57)
Configuration A
NOTES:
1. Dimensions are in inches.
2. Unless otherwise specified, tolerance is ±.005 inch (0.13 mm).
FIGURE 1. Configuration A and dimensions.
