A-A-55495 Fuse Cartridge, Semiconductor Type, 500 VoltsThis commercial item description \(CID\) covers the general requirements for 500 volt semiconductor type fuse cartridges. Fuse cartridges covered by this CID are intended for commercial/industrial applications.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8


A-A-55495D
AA55495-
Dimensions
A
B
C
001
through
2.00 (50.80)
.563 (14.30)
.505 (12.83)
006
Configuration A
NOTES:
1. Dimensions are in inches.
2. Unless otherwise specified, tolerance is ± .005 inch (0.13 mm).
FIGURE 1. Configuration A and dimensions.
