[INCH-POUND]
A-A-55518/1A
December 10, 2001
SUPERSEDING
A-A-55518/1
March 1, 1996
COMMERCIAL ITEM DESCRIPTION
SPECIFICATION SHEET
FUSEHOLDER, BLOCK, 2 AMPERES (A), 250 VOLTS (V) AC, 1 THROUGH
12 POLE, ACCOMMODATES 8AG TYPE FUSE CARTRIDGES
The General Services Administration has authorized the use of this
Commercial Item Description (CID) for all federal agencies.
The complete requirements for procuring the fuseholders described herein shall consist of this document
and the issue in effect of CID A-A-55518.
CLASSIFICATION. This CID uses a classification system that is included in the Part Identification
Number (PIN) as shown in the following example (see notes).
-
001
AA55518/01
CID
Dash number
number
(see table I)
SALIENT CHARACTERISTICS.
Interface and physical dimensions. Fuseholder blocks supplied to this CID shall be as specified herein
(see figure 1).
Ampere rating. The ampere rating shall be 2 A maximum.
Voltage rating. The voltage rating shall be 250 V ac maximum.
Fuse accommodation. This fuseholder accommodates 8AG type fuse cartridges with dimensions of .25
inch x 1.0 inch (6.4 mm x 25.4 mm).
Fuseholder base. The fuseholder base shall be molded or laminated plastic.
Lug and terminal material. The lug and terminal material for AA55518/01-01 shall be brass.
Fuse clips. Fuseholders AA55518/01-001 through AA55518/01-007 shall be supplied with CID number
AA55507/01-09 or CID number AA55507/01-11 fuse clips.
PIN. The PIN should be used for Government purposes to buy commercial products to this CID. See
classification information for PIN format example.
AMSC N/A
FSC 5920
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
