MIL-DTL-24646/18B
REQUIREMENTS
Symbol numbers: See table I.
Design:
Electrical rating: 125 volts, 0-30 ampere.
Dimensions and configuration: See figures 1, 2, 3 and 4.
Wiring diagrams: See figure 5.
Mounting dimensions: See figure 3.
Degree of enclosure: Submersible (15 feet).
Designation and marking: See MIL-DTL-24646.
Parts: The parts listed in table II and specified in MIL-DTL-24646 shall be used in the construction of
the fuse boxes specified herein.
General information:
Military part numbers and general information are as specified in table I.
TABLE I. Military part numbers and general information.
Supersedes
Bus bar
Fuse
Branch
Feeder
No. of
Weight
Symbol
Military
size
size
MCM
MCM
circuits
in
no.
part no.
Type
Drawing
pounds
no.
M24646/18-
671.1
4.0
1
---
---
0-30A
0.50 x 0.25
9000-S-6202-74028
-
001
TABLE II. Parts list.
Remarks
Material/
Description
Item
QTY M
specification
no. 1/
/-
001
01
Fuse box assembly
-
MIL-DTL-24646/18
See figure 1
(sym 671.1)
02
Enclosure (5R)
1
M24142/5-003
See figure 2
03
Fuse block assembly
1
MIL-DTL-24646/18
See figure 4
04
Fuse clip (midget 0-30A)
4
A-A-55507/01-04
N/A
05
Identification plate
1
Brass, ASTM B36/B36M
N/A
06
Information plate
1
Brass, ASTM B36/B36M
N/A
1/ Item numbers after the figure titles are the same as the item
numbers shown in this table.
Referenced documents. In addition to MIL-DTL-24646, this document references the following:
