MIL-DTL-5372/1B
REQUIREMENTS:
TABLE I. Ampere rating.
Dash number
Current rating
M5372/1-
amperes
01
1
02
2
03
3
05
5
10
10
15
15
20
20
25
25
30
30
35
35
40
40
50
50
60
60
Dimensions, marking, and configuration: See figure 1.
Voltage rating. 115/200 volts ac, 400 Hz, 28 volts dc.
Weight. 0.065 pounds maximum.
Materials. Body: Glass filled melamine in accordance with ASTM-D5948 type MMI-5 (white). Blades:
Copper in accordance with ASTM-B152/B152M, type ETA with silver plate.
Terminal strength. With body of the fuse firmly clamped, the forces below shall be applied to both
terminals.
TABLE II. Terminal strength.
Direction of force
Rating
To 30 amperes
Above 30 amperes
Force in pounds (minimum)
To edge of blade
10
25
To flat side of blade
5
10
To end of blade (into fuse)
30
40
3
