MIL-DTL-83413/2C
REQUIREMENTS
Design and configuration: See figure 1.
Grounding plug: In accordance with MIL-DTL-83413/4.
Grounding wire: 7 X 7 wire in accordance with MIL-DTL-83420, type II, composition B, jacket color
translucent (see PIN example), or international orange in accordance with FED-STD-595/22510.
Terminal: In accordance with SAE-AS20659 terminal shall accommodate .375 inch stud.
Splices shall not be used.
Assembly resistance: Resistance of the grounding assembly shall not exceed 6 ohms.
Part or Identifying Number (PIN) example:
M83413
/2
-
40 T
Basic specification
Specification sheet
Wire length (feet)
(see dimension A)
Optional jacket color
(T = Translucent, if no letter = international orange)
Wire length shall be 10, 20, 30, or 40 feet + 1 foot.
QUALIFICATION
Qualification is not required for this specification sheet. First article inspection shall be a visual
and mechanical inspection in accordance with MIL-DTL-83413.
Changes from previous issue. The margins of this specification are marked with vertical lines to indicate
where changes from the previous issue were made. This was done as a convenience only and the
Government assumes no liability whatsoever for any inaccuracies in these notations. Bidders and
contractors are cautioned to evaluate the requirements of this document based on the entire content
irrespective of the marginal notations and relationship to the last previous issue.
Referenced documents. In addition to MIL-DTL-83413, this document references the following:
SAE-AS20659
MIL-DTL-83413/4
MIL-DTL-83420
FED-STD-595/22510
