MIL-PRF-15160/15H
REQUIREMENTS:
Case: Fiber or alternate material.
(Alternate to fiber material (tube) shall have an average burst strength of 2,100 pounds per
square inch with a value of not less than 1,450 pounds per square inch).
Ferrule: Brass.
Finish: Nickel, bright alloy, or bright dipped, silver plated when specified.
Terminal strength: Method 211 of MIL-STD-202, test condition E, 5 inch-pound torque between
ferrules and fuse body.
Electrical:
Electrical requirements shall be as specified in table I.
Shock: Method 207 of MIL-STD-202, HI shock.
Vibration: Method 204 of MIL-STD-202, test condition A (except 5g peak).
TABLE I Electrical requirements.
Characteristic
A
BR
Voltage rating
250 V ac
250 V ac
250 V dc
250 V dc
450 V rms ac
N/A
Overload test 1/
135%
0 1 hour
0 1 hour
500%
N/A
10 25 seconds
Short circuit test
at 250 V dc
10,000A
10,000A
at 250 V ac
N/A
200,000A
(20% PF max.)
(50% PF max.) 3/
at 450 V rms ac 2/
0 20A fuse
8,000A
N/A
25 30A fuse
1,500A
N/A
1/ Overload is shown as a percentage of the current rating of
the fuse.
2/ Characteristic A fuses may be used for 450 V rms ac.
3/ Power factor (PF).
