MIL-PRF-15160/19F
TABLE I Electrical requirements.
Characteristics
BR
Voltage rating
250 V ac
250 V dc
Overload test 1/
135%
0 2 hour
500%
10 25 seconds
Short circuit test
at 250 V dc
10,000A
at 250 V ac
200,000A
(20% PF max.) 2/
1/ Overload is shown as a percentage of the
current rating of the fuse.
2/ Power factor (PF).
Part or Identifying Number (PIN): The PIN shall be constructed from table II (e.g., F19BR250V80A).
TABLE II Part or Identifying Number. 1/ 2/
Style
Characteristic
Maximum
Current rating
voltage
F19
BR
3/
250 V
70A
F19
BR
3/
250 V
80A
F19
BR
3/
250 V
90A
F19
BR
3/
250 V
100A
1/ For silver plated terminals, the designator "S" is added after the
current rating.
2/ The characteristic A fuse has been discontinued without replacement.
3/ The characteristic B fuse has been discontinued. The characteristic
BR fuse may be used to replace the old characteristic B fuse of the
same current rating.
VERIFICATION:
Qualification inspections: The number of qualification samples required shall be:
a. 24 samples maximum current rating of each voltage and design.
b. 24 samples minimum current rating of each voltage and design.
NOTE: If labels are used, five additional samples of any rating are required.
3
