TABLE I Type designations and electrical rating Continued.
AC short circuit interrupt.
Type designation
Overload interrupt time 2/
Style
Characteristic
Maximum
Current
135% of rating Max. 1 hour
voltage
rating 3/
200% of rating
300% of rating
32 volts
125 volts
250 volts
(amperes)
(seconds)
(seconds)
F02
B
250V
3A
4.0 90.0
1.5 30.0
10,000A
10,000A
35A
F02
B
250V
3 2/10A
4.0 90.0
1.5 30.0
10,000A
10,000A
35A
F02
1/
B
125V
4A
4.0 90.0
1.5 30.0
10,000A
10,000A
Not rated
F02
B
125V
5A
4.0 90.0
1.5 30.0
10,000A
10,000A
Not rated
F02
1/
B
125V
6 1/4A
4.0 90.0
1.5 30.0
10,000A
10,000A
Not rated
F02
1/
B
125V
7A
4.0 90.0
1.5 30.0
10,000A
10,000A
Not rated
F02
B
32V
8A
4.0 700.0
1.0 30.0
10,000A
Not rated
Not rated
F02
B
32V
10A
4.0 700.0
1.0 30.0
10,000A
Not rated
Not rated
F02
1/
B
32V
12A
4.0 700.0
1.0 30.0
10,000A
Not rated
Not rated
F02
B
32V
15A
4.0 700.0
1.0 30.0
10,000A
Not rated
Not rated
F02
B
32V
20A
4.0 700.0
1.0 30.0
10,000A
Not rated
Not rated
F02
1/
B
32V
25A
4.0 700.0
1.0 30.0
10,000A
Not rated
Not rated
F02
1/
B
32V
30A
4.0 700.0
1.0 30.0
10,000A
Not rated
Not rated
1/ INACTIVE FOR NEW DESIGN AFTER 30 JANUARY 1970.
2/ The overload interrupt time ranges, as shown, cover the temperature range from minus 55°C to plus 85°C.
For characteristic B, the overload interrupt time at room ambient temperature shall be not less than 12 seconds at
200 percent rating.
3/ For silver plated terminals the designator "S" is added after the current rating.
