MIL-PRF-15160/20F
Inches
mm
Ltr
Min
Max
Min
Max
A
7.063
7.187
179.40
182.55
B
---
1.688
---
42.88
C
1.375
---
34.93
---
D
1.188
---
30.18
---
E
.990
1.160
25.15
29.46
F
---
1.876
---
47.65
G
.165
.171
4.19
4.34
H
.407
.469
10.34
11.91
J
.276
.306
7.01
7.77
K
---
.125
---
3.18
L
.622
.754
15.80
19.15
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
FIGURE 1. Style F20 characteristic BR - Continued.
REQUIREMENTS:
Interface and physical dimensions: See figure 1.
Case: Fiber or alternate material.
(Alternate to fiber material (tube) shall have an average burst strength of 2,300 pounds per
square inch with a value of not less than 1,900 pounds per square inch).
Knifeblade: Copper.
Finish: Nickel, bright alloy, or bright dipped, silver plated when specified.
Terminal strength: Method 211 of MIL-STD-202, test condition E, 5 inch-pound torque between
ferrules and fuse body.
Electrical:
Electrical requirements shall be as specified in table I.
Shock: Method 207 of MIL-STD-202, HI shock.
Vibration: Method 204 of MIL-STD-202, test condition A (except 5g peak).
Temperature: Temperature rise shall be not greater than the values shown in table II.
2
