MIL-PRF-15160/28D
REQUIREMENTS:
Interface and physical dimensions: See figure 1.
Body: Fiber.
Ferrule: Brass.
Finish: Nickel or bright alloy or bright dipped, silver plated when specified.
Terminal strength: 2 inch-pounds.
Type designation: Type designation shall be as specified in table 1.
Electrical:
Voltage rating: 2,500 volts maximum.
Overload interrupt: Maximum 1 hour at 135 percent of rated current..
Short circuit interrupt: 5 amperes at 2,500 volts ac.
Current capacity: Maximum 1.5 hours at 110 percent of rated current.
Current rating: See table I.
Voltage rating: See table I.
Characteristic: See table I.
Part or Identifying Number (PIN): The PIN shall be constructed from table I (e.g., F28A2500V1A).
TABLE I. Part or Identifying Number 1/
Style
Characteristic
Voltage
Current
F28
A
2,500
½A
F28
A
2,500
¾A
F28
A
2,500
1A
F28
A
2,500
1½A
F28
A
2,500
2A
1/ For silver plated terminals, the designator "S" is added after the
current rating.
VERIFICATION:
Qualification inspection is not applicable for this specification sheet and is replaced by acceptance
testing which shall consist of group A and group B inspection of MIL-PRF-15160.
