MIL-PRF-15160/29B
REQUIREMENTS:
Interface and physical dimensions: See figure 1.
Body: Fiber.
Ferrule: Brass.
Finish: Nickel or bright alloy or bright dipped, silver plated when specified.
Terminal strength: 5 inch-pounds.
Type designation: Type designation shall be as specified in table 1.
Electrical:
Voltage rating: 5,000 volts maximum.
Overload interrupt: Maximum 1 hour at 135 percent of rated current.
Short circuit interrupt: 5 amperes at 5,000 volts ac.
Current capacity: Maximum 1.5 hours at 110 percent of rated current.
Current rating: See table 1.
Voltage rating: See table 1.
Characteristic: See table 1.
Part or Identifying Number (PIN): The PIN shall be constructed from table I (e.g., F29A5000V1/16A).
TABLE I. Part or Identifying Number. 1/
Style
Characteristic
Voltage
Current
F29
A
5,000
1/16 A
F29
A
5,000
1/8 A
F29
A
5,000
1/4 A
F29
A
5,000
3/8 A
F29
A
5,000
1/2 A
F29
A
5,000
3/4 A
F29
A
5,000
1A
F29
A
5,000
1 1/2 A
F29
A
5,000
2A
F29
A
5,000
3A
1/ For silver plated terminals, the designator "S" is added after the
current rating.
VERIFICATION:
Qualification is not applicable for this specification sheet and is replaced by successful completion of
Group A and Group B inspections in MIL-PRF-15160, before product is delivered.
