MIL-PRF-15160/30B
REQUIREMENTS:
Interface and physical dimensions: See figure 1.
Body: Fiber.
Ferrule: Brass.
Finish: Nickel or bright alloy or bright dipped, silver plated when specified.
Terminal strength: 5 inch-pounds.
Type designation: Type designation shall be as specified in table 1.
Electrical:
Voltage rating: 10,000 volts maximum.
Overload interrupt: Maximum 1 hour at 135 percent of rated current.
Short circuit interrupt: 5 amperes at 10,000 volts ac.
Current capacity: Maximum 1.5 hours at 110 percent of rated current.
Current rating: See table 1.
Voltage rating: See table 1.
Characteristic: See table 1.
TABLE 1. Type designation and electrical rating. 1/
Style
Characteristic
Voltage
Current
F30
A
10,000
.06 A
F30
A
10,000
.12 A
F30
A
10,000
.25 A
F30
A
10,000
.38 A
F30
A
10,000
.50 A
F30
A
10,000
.75 A
F30
A
10,000
1A
F30
A
10,000
1.5 A
F30
A
10,000
2A
F30
A
10,000
3A
1/ For silver plated terminals, the designator "S" is added after the
current rating.
VERIFICATION:
Qualification is not applicable for this specification sheet and is replaced by successful completion of group A
and group B inspections in MIL-PRF-15160, before product is delivered.
