MIL-PRF-15160/36B
REQUIREMENTS:
Interface and physical dimensions: See figure 1.
Body: Fiber.
Ferrule: Brass.
Terminal strength: 5 inch-pounds.
Type designation: Type designation shall be as specified in table 1.
Electrical:
Voltage rating: 125 volts dc maximum.
Overload interrupt:
Characteristic A: Maximum 1 hour at 135 percent of rated current.
Characteristic B: Maximum 1 hour at 135 percent of rated current, and a minimum of 30 seconds at
300 percent
Short circuit interrupt: 10,000 amperes at 125 volts dc.
Current rating: See table 1.
Voltage rating: See table 1.
Characteristic: See table 1.
TABLE 1. Type designation and electrical rating.
Style
Characteristic
Voltage
Current
F36
A
125 V
1A
F36
A
125 V
2A
F36
A
125 V
3A
F36
A
125 V
5A
F36
A
125 V
10 A
F36
A
125 V
15 A
F36
B
125 V
1A
F36
B
125 V
2A
F36
B
125 V
3A
F36
B
125 V
5A
F36
B
125 V
10 A
F36
B
125 V
15 A
VERIFICATION:
Qualification is not applicable for this specification sheet and is replaced by successful completion of group A and
group B inspections in MIL-PRF-15160, before product is delivered.
2
