MIL-PRF-15160/50D
REQUIREMENTS:
Interface and physical dimensions: See figure 1.
Body: Plastic sheet.
Terminal: Copper.
Finish: Natural or tin plated.
Terminal strength: Method 211 of MIL-STD-202, test condition E, 2 inch-pound torque between
ferrules and fuse body.
Electrical:
Current rating: See table I.
Voltage rating: See table I.
Current carrying capacity: 100 percent normal rating.
Characteristic: See table I.
Overload interrupt:
Characteristic A within 1 hour at 135 percent of rated current.
Characteristic A within 60 seconds at 200 percent of rated current.
Short circuit interrupt 20 amperes at 90 volts dc.
Part or Identifying Number (PIN): The PIN shall be constructed from table I (e.g., F50A90V1/2A).
TABLE I. Part or Identifying Number.
Style
Characteristic
Maximum
Current rating
voltage
F50
A
90 V
1/2 A
F50
A
90 V
1 1/3 A
F50
A
90 V
2A
VERIFICATION:
Qualification inspection is not applicable for this specification sheet and is replaced by acceptance
testing which shall consist of group A and group B inspection of MIL-PRF-15160.
