MIL-PRF-15160/51B
REQUIREMENTS:
Interface and physical dimensions: See figure 1.
Material:
Body: Plastic sheet.
Terminal: Copper.
Finish: Natural or tin plated.
Alarm springs: May be nickel silver.
Terminal strength: MIL-STD-202, method 211, 2 pound pull.
Electrical:
Current rating: See table II.
Voltage rating: See table II.
Current carrying capacity: 100 percent normal rating.
Characteristic: See table II.
Overload interrupt: See table I.
Short circuit interrupt: 20 amperes at 90 volts dc.
Type designation: Type designation shall be as specified in table II.
Qualification: Qualification not required.
TABLE I. Overload interrupt.
Fuse
Percent
Normal
current
nominal
blowing
rating
rating
rate
.50
150
0-1.5
min
1.33
150
0-1.5
min
2.00
150
0-3 min.
