MIL-PRF-15160/62H
REQUIREMENTS:
Interface and physical dimensions: See figure 1.
Case: Glass melamine.
Ferrule: Brass, copper, bronze, or copper alloy.
Finish: Nickel or bright alloy plate, silver plated when specified.
Terminal strength: Method 211 of MIL-STD-202, test condition E, 2 pound-inch torque between
ferrules
and fuse body.
Electrical:
Current rating: See table I.
Current carrying capacity: 110 percent of rated current.
Voltage rating: See table I.
Characteristic: Characteristic C only.
Overload interrupt: Within 1 hour at 135 percent of rated current; and within 4 minutes at 200 percent.
Short circuit interrupt: 200,000 A at 500 V ac (symmetrical), 150,000 A at 500 V dc.
Shock: Method 207 of MIL-STD-202, HI shock.
Vibration: Method 204 of MIL-STD-202, test condition A (except 5g, 500 Hz).
Part or Identifying Number (PIN): The PIN shall be constructed from table I (e.g., F62C500V35A).
TABLE I. Type designation. 1/
Style
Characteristic
Voltage
Current
F62
C
500V
35A
F62
C
500V
40A
F62
C
500V
45A
F62
C
500V
50A
F62
C
500V
60A
1/ For silver plated terminals, the designator "S" is added after
the current rating.
