MIL-PRF-19207/17H
Dielectric:
Sea level: 1,500 volts.
Reduced pressure: 625 volts.
EMI/RFI shielding: Paragraph 3.5.18 of MIL-PRF-19207.
Part or Identifying number (PIN): Watertight (FHN28W), watertight with EMI/RFI shielding (FHN28WS),
watertight and body sealed (FHN28WB) or watertight and body seal with EMI/RFI shielding
(FHN28WBS).
TABLE I. Supersession information.
Superseding PIN
Superseded MIL
designation number
dash number
FHN28W
M19207/17-001
FHN28WS
N/A
FHN28WB
M19207/17-002
FHN28WBS
N/A
NOTES:
1. Body molding material: It is recommended that type MAI-60 or GDI-30F of American Society For
Testing and Materials (ASTM) ASTM D5948 be considered for meeting the body molding material
requirements of this specification.
2. EMI/RFI shielded type fuseholders are equivalent to the non-shielded type fuseholders with the
addition of EMI/RFI shielding cap and mounting nut assembly.
3. To assure maximum shielding effectiveness mounting nut must be torqued to 15-20 inch-pounds
over an electrically conductive panel surface, 1.01 inch minimum diameter.
4. For submarine applications, order type FHN28WB and FHN28WBS.
Referenced documents. In addition to MIL-PRF-19207, this document references the following:
The margins of this specification are marked with vertical lines to indicate where changes from the
previous issue were made. This was done as a convenience only and the Government assumes no
liability whatsoever for any inaccuracies in these notations. Bidders and contractors are cautioned to
evaluate the requirements of this document based on the entire content irrespective of the marginal
notations and relationship to the last previous issue.
4
