MIL-PRF-19207/2J
Ltr
Inches
mm
Ltr
Inches
mm
Min
Max
Min
Max
Min
Max
Min
Max
A
1.060
1.080
26.92
27.43
L
.435
.445
11.05
11.30
B
.745
.755
18.92
19.18
M
.850
.860
21.59
21.84
C
.435
.445
11.05
11.30
N
.385
.425
9.78
10.80
D
.188
.198
4.78
5.03
P
.140
.160
3.56
4.06
E
.870
.880
22.10
22.35
R
.695
.705
17.65
17.91
F
.385
.395
9.78
10.03
S
.565
.605
14.35
15.37
G
1.190
1.210
30.23
30.73
T
.140
.190
3.56
4.83
H
.945
.955
24.00
24.26
U
1.675
---
42.55
---
J
.125
---
3.18
---
V
1.950
2.050
49.53
52.07
K
.360
.370
9.14
9.40
W
2.105
2.155
53.47
54.74
Part or Identifying Number (PIN):
FHL11U-001 - Body for FHL11U
FHL11G-002 - Body for FHL11G
NOTES: Fuse carrier for FHL11U-001 shall be FHL10U-003.
Fuse carrier for FHL11G-002 shall be FHL10G-004.
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerances are ± 0.02 (0.51 mm) for two place decimals and ±0.005 (0.13mm) for
three-place decimals.
FIGURE 2. Body for FHL11U and FHL11G fuseholders.
