MIL-PRF-19207/25G
Test fuses:
Temperature rise: F60C500V30A of MIL-PRF-15160/60.
Voltage drop:
F60C500V30A of MIL-PRF-15160/60.
F60C500V30A of MIL-PRF-15160/60.
Short circuit:
Mechanical shock: Method I of MIL-PRF-19207.
Terminal strength: 20 pounds.
Torque: Terminal - 25 inch- pounds.
Mounting - 15-20 inch- pounds.
Cap insert - 30 inch-pounds.
Salt spray (corrosion): Test condition B.
Dielectric:
Sea level: 2,000 volts
Reduced pressure: 750 volts
EMI/RFI shielding: Paragraph 3.5.18 of MIL-PRF-19207.
Part or Identifying Number (PIN): Watertight (FHN41W), watertight with EMI/RFI shielding (FHN41WS),
watertight and body sealed (FHN41WB) or watertight and body sealed with EMI/RFI shielding
(FHN41WBS).
TABLE I Supersession information.
Superseding PIN
Superseded MIL
dash number
FHN41W
M19207/25-001
FHN41WS
N/A
FHN41WB
M19207/25-002
FHN41WBS
N/A
NOTES:
1. Body molding material: It is recommended that type MAI-60 or GDI-30F of American Society
For Testing and Materials ASTM-D5948 be considered for meeting the body molding material
requirements of this specification.
2. For submarine applications use FHN41WB or FHN41WBS.
3. EMI/RFI shielded type fuseholders are equivalent to the non-shielded type fuseholders with the
addition of EMI/RFI shielding cap and mounting nut assembly.
4. To assure maximum shielding effectiveness mounting nut must be torqued to 15-20 inch-pounds
over an electrically conductive panel surface, 1.26 inch minimum diameter.
