MIL-PRF-19207/28G
REQUIREMENTS:
Cap and body molding material: Cap and body molding materials shall be selected to enable the fuseholder
to meet the performance requirements of this specification. Additional information and guidance on cap and
body molding material are specified in the notes.
Fuse accommodation:
Miniature plug type: FM02: MIL-PRF-23419/2. Fuse is not captive in cap at removal.
(or equivalent size and style)
Poles: One.
Rating: 5 amperes (see table I for voltage).
Panel thickness: 0.187 inch (4.75 mm) maximum.
Indicating: Incandescent lamp 1762X or 1764 with amber color cap.
Lamp series resistor: See table I.
Terminals: Solder lug type.
Enclosure: Dripproof.
Gaskets: Gaskets shall be used that enable the fuseholder to meet the performance requirements of this
specification. Additional information and guidance on gaskets are specified in the notes.
Test fuses: FM02A125V5A of MIL-PRF-23419.
Marking: In addition to other required marking, a dash number shall follow the type designation and shall be
associated with the voltage rating in accordance with table I.
Mechanical shock: Method I of MIL-PRF-19207.
Thermal shock: Method 107, test condition B, MIL-STD-202.
Endurance: 500 insertions and removals of cap and fuse.
Torque:
Cap: 4 pounds-inch.
Mounting: 10 pounds-inch.
Salt spray (corrosion): Test condition B.
Part or Identifying Number (PIN): FHL44G (dash number from table l).
TABLE I. Voltage and resistance.
Dash
Voltage
Resistance ohms
Resistor
Resistor
number
style
specification
1
---
---
Shorting wire in place of resistor
12-22
2
RLR-20
330
23-33
3
RWR-89
680
34-45
4
RWR-89
1,200
46-60
5
RWR-89
1,800
61-80
RWR-89
2,000
81-90
6
2
