MIL-PRF-19207/30F
Gaskets and O-rings: Gaskets and O-rings shall be used that enable the fuseholder to meet the performance
requirements of this specification. Additional information and guidance on gaskets and O-rings are specified in the
notes.
Test fuses:
Temperature rise: F03A125V30A of MIL-PRF-15160/3.
F03A125V30A of MIL-PRF-15160/3.
Voltage drop:
F03A250V15A of MIL-PRF-15160/3.
Short circuit:
Mechanical shock: Method I of MIL-PRF-19207.
Terminal strength: 20 pounds.
Torque: Cap - 36 inch-pounds, terminal - 12 inch-pounds.
Salt spray (corrosion): Test condition B.
Dielectric:
Sea level:
1,500 volts.
Reduced pressure:
625 volts.
Mounting hardware:
Screw:
6-32UNC-2A, Round head with sealing washer.
Nut:
6-32UNC-2B Hex. A threaded metal insert may be used in lieu of nut.
Type designation: See table I.
Part or Identifying Number (PIN): FHN46W or FHN46WB, depending on type, see table I.
TABLE I
Superseding PIN
Superseded military part number
FHN46W
M19207/30-001
FHN46WB
M19207/30-002
Referenced documents. In addition to MIL-PRF-19207, this document references the following:
