MIL-PRF-23419/8J
Qualification and group C Inspection:
Inspection routine: The number of group II samples for qualification and subgroup 2 samples for
group C inspection shall be as shown in table II.
Table II. Group II and subgroup 2 samples.
Inspection
Number of sample fuses
Group II and subgroup 2
16
Terminal strength
4
Overload interrupt
200% at -55° C
4
200% at +125° C
4
300% at -55° C
4
300% at +125° C
4
The number of group III samples for qualification (or first article) testing shall consist of four sample
fuses of each of the current ratings as shown in table III. Short circuit interrupt tests shall be
conducted at the direct current voltage indicated, and the fuses shall be capable of withstanding a
minimum short circuit current as shown in table III
TABLE III. Short circuit tests.
Fuse style
Current rating
Short circuit current
DC voltage
FM08
10A
300A
125
FM08
15A
300A
32
Supersession data: See table IV.
TABLE IV. Supersession data.
Superseding PIN
Superseded numbers in accordance
Superseded numbers in accordance
designation
with MIL-PRF-23419/8B
with MIL-PRF-23419/8A
FM08A125V1/8A
FM08125V1/8A
FM08-125V-1/8A
FM08A125V1/4A
FM08125V1/4A
FM08-125V-1/4A
FM08A125V3/8A
FM08125V3/8A
FM08-125V-3/8A
FM08A125V1/2A
FM08125V1/2A
FM08-125V-1/2A
FM08A125V3/4A
FM08125V3/4A
FM08-125V-3/4A
FM08A125V1A
FM08125V1A
FM08-125V-1A
FM08A125V1-1/2A
FM08125V1-1/2A
FM08-125V-1-1/2A
FM08A125V2A
FM08125V2A
FM08-125V-2A
FM08A125V2-1/2A
FM08125V2-1/2A
FM08-125V-2-1/2A
FM08A125V3A
FM08125V3A
FM08-125V-3A
FM08A125V4A
FM08125V4A
FM08-125V-4A
FM08A125V5A
FM08125V5A
FM08-125V-5A
FM08A125V7A
FM08125V7A
FM08A125V10A
FM08125V10A
FM08A32V15A
FM08125V15A
4
