INCH-POUND
MIL-PRF-23419H
7 February 2013
SUPERSEDING
MIL-PRF-23419G
24 June 2005
PERFORMANCE SPECIFICATION
FUSE, CARTRIDGE, INSTRUMENT TYPE,
GENERAL SPECIFICATION FOR
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
1. SCOPE
1.1 Scope. This specification covers the general requirements and test procedures for instrument type
fuses designed for the protection of electrical, electronic, and communication equipment on direct current
(dc) and alternating current (ac) (up to 400 hertz (Hz)) circuits.
1.2 Classification.
1.2.1 Part or Identifying number (PIN). The PIN designation is in the following form and as specified
FM08
A
125 V
1/2 A
*
Style
Characteristic
Voltage rating
Current rating
Optional finish
(1.2.1.1)
(1.2.1.2)
(1.2.1.3)
(1.2.1.4)
(1.2.1.5)
1.2.1.1 Style. The style is identified by the letters "FM" followed by a two-digit number denoting a fuse
of a given construction and dimensions.
1.2.1.2 Characteristic. The characteristic is identified by a one-letter symbol which indicates the
relative overload interrupt time (see 6.5) in accordance with table I.
TABLE I. Characteristics.
Symbol
Relative overload interrupt time
A
Normal
B
Time delay
Comments, suggestions, or questions on this document should be addressed to: DLA Land and Maritime,
ATTN: DLA Land and Maritime-VAT, Post Office Box 3990, Columbus, Ohio 43218-3990 or emailed to
mailto:CircuitProtect@dla.mil. Since contact information can change, you may want to verify the
currency of this address information using the ASSIST Online database at https://assist.dla.mil.
AMSC N/A
FSC 5920
