A-A-55429D
TABLE I. Characteristics.
AA55429-
Characteristics
001
1 pole with screw connectors. Fuse clips with reinforcing springs.
002
1 pole with box lug connectors. Fuse clips with reinforcing springs.
003
2 pole with screw connectors. Fuse clips with reinforcing springs.
004
2 pole with box lug connectors. Fuse clips with reinforcing springs.
005
3 pole with screw connectors. Fuse clips with reinforcing springs.
006
3 pole with box lug connectors. Fuse clips with reinforcing springs.
3.6 Wire size. The maximum wire size shall be #1/0 CU-AL for screw connectors and screw with
pressure plate connectors and #6/0 CU-AL for box lug connectors.
3.7 Reinforcing spring. Reinforcing springs are used for reinforcement of the fuse clip. Spring reinforced
fuse clips are recommended if frequent fuse replacement is expected.
3.8 Fuse accomodation. This fuseholder accepts class H fuses with dimensions of 7.875 inches, (200.02
mm) a blade thickness of .125 inch (3.17 mm), and a blade width of .750 inch (19.05 mm).
3.9 Marking. Fuseholders supplied to this CID shall be marked with the manufacturer s (MFR s) standard
commercial PIN and the UL listing mark. (NOTE: The part number marked on the unit pack shall be the
CID PIN.)
3.10 Recycled, recovered, or environmentally preferable materials. Recycled, recovered, or
environmentally preferable materials should be used to the maximum extent possible provided that the
material meets or exceeds the operational and maintenance requirements, and promotes economically
advantageous life cycle costs.
3.11 Workmanship. Fuseholders shall be processed in such a manner as to be uniform in quality and
shall be free from other defects that will affect life, serviceability, or appearance.
4. REGULATORY REQUIREMENTS. The offeror/contractor is encouraged to use recovered materials to
the maximum extent practicable, in accordance with 23.403 of the Federal Acquisition Regulation (FAR).
5. PRODUCT CONFORMANCE PROVISIONS
5.1 Product conformance. The products provided shall meet the salient characteristics of this CID,
conform to the producer s own drawings, specifications, standards, and quality assurance practices, and
be the same product offered for sale in the commercial market. The Government reserves the right to
require proof of such conformance.
5.2 Market acceptance. The following market acceptance criteria are necessary to document the quality
of the product to be provided under this CID:
a. The company producing the item must have been producing a product meeting the requirements
of this CID for at least 2 years.
b. The company producing the item must have sold 1,000 units meeting this CID in the commercial
marketplace over the past 2 years.
6. PACKAGING. Preservation, packing, and marking shall be as specified in the contract or order.
4
