A-A-55492 Fuse Cartridge, Semiconductor Type, 130 VoltsThis commercial item description \(CID\) covers the general requirements for 130 volt semiconductor type fuse cartridges. Fuse cartridges covered by this CID are intended for commercial/industrial applications.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7

A-A-55492D

AA55492-

Dimensions

001

1.500

.406

.374

through

(38.10)

(10.31)

(9.50)

006

.631

007

2.000

.811

(16.03)

through

(50.80)

(20.60)

.495

011

(12.57)

Configuration A

NOTES:

1. Dimensions are in inches.

2. Unless otherwise specified, tolerance is �.005 inch (0.13 mm).

FIGURE 1. Configuration A and dimensions.
