[INCH-POUND]
A-A-55504/5C
9 May 2011
SUPERSEDING
A-A-55504/5B
20 January 2006
COMMERCIAL ITEM DESCRIPTION
SPECIFICATION SHEET
FUSEHOLDER, EXTRACTOR POST, FRONT MOUNT, LOW PROFILE, SCREWDRIVER
KNOB FUSE CARRIER FOR 3AG (.25 INCH (IN) X 1.25 IN (6.35 MILLIMETERS (MM) X 31.75 MM)) OR
.196 IN X .787 IN (5 MM X 20 MM) FUSE CARTRIDGES
The General Services Administration has authorized the use of this
commercial item description (CID) for all federal agencies.
The complete requirements for procuring the fuseholders described herein shall consist of this document
and the issue in effect of CID A-A-55504.
CLASSIFICATION/PART OR IDENTIFICATION NUMBER (PIN). This commercial item description (CID)
specification sheet uses a classification system which is included in the PIN as shown in the following
example (see NOTES).
Rear terminal
AA55504/05-
Accommodates fuse
configuration
001A
3AG
A
001B
3AG
B
001C
3AG
C
001D
3AG
D
002A
5 mm x 20 mm
A
002B
5 mm x 20 mm
B
002C
5 mm x 20 mm
C
002D
5 mm x 20 mm
D
SALIENT CHARACTERISTICS.
Interface and physical dimensions. Fuseholders supplied to this CID specification sheet shall be as
specified herein (see figure 1).
Rear terminal configuration. The rear terminal configuration shall be as specified in A-A-55504.
Mounting hole. The mounting hole shall be as specified in figure 1.
NOTES.
PIN. The PIN should be used for Government purposes to buy commercial products to this CID
specification sheet. See classification information for PIN format example.
AMSC N/A
FSC 5920
