MIL-DTL-24646-10 Fuse Boxes, Feeder Distribution, Submersible, \(15 Feet\), 250 Volts, Alternating Current, Three Phase Buses, Single And Three Phase Branches, 0-30 Ampere Fuses, Symbols 560.1, 561.1, 562.1, And 563.1

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8


MIL-DTL-24646/10B
A. Symbols 562.1
B. Symbols 560.1, 561.1, and 563.1
DIMENSIONS
SYMBOL
NO
A
B
560.1
9.25
4.62
561.1
12.00
6.00
563.1
9.25
4.62
FIGURE 3. Mounting dimensions, ref.
3
