MIL-DTL-24646-8 Fuse Boxes, Feeder Distribution, Submersible, \(15 Feet\), 125 Volts, Alternating Current, Three Phase Buses, Single Phase Branches, 0-30 Ampere Midget Fuses Symbols 646.1 And 647.1

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7


MIL-DTL-24646/8B
SYMBOL
DIMENSIONS (REF)
NO
A
B
C
646.1
16.38
13.38
5.62
647.1
21.38
13.38
5.62
FIGURE 2. Enclosure, overall dimensions. Item No. 03, 04
(Symbols 646.1 and 647.1)
2
