MIL-DTL-24646-8 Fuse Boxes, Feeder Distribution, Submersible, \(15 Feet\), 125 Volts, Alternating Current, Three Phase Buses, Single Phase Branches, 0-30 Ampere Midget Fuses Symbols 646.1 And 647.1

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7


MIL-DTL-24646/8B
DIMENSIONS (REF)
SYMBOL
NO
A
B
646.1
9.25
4.62
647.1
14.25
7.12
FIGURE 3. Mounting dimensions, ref.
(Symbols 646.1 and 647.1)
3
