MIL-PRF-15160/10H
TABLE I Type designations and electrical rating. 1/
Style
Characteristic
Maximum
Current
voltage
rating
F10
A
250V
1A
F10
A
250V
2A
F10
A
250V
3A
F10
A
250V
4A
F10
A
250V
5A
F10
A
250V
6A
F10
A
250V
8A
F10
A
250V
10A
F10
A
250V
12A
F10
A
250V
15A
F10
A
125V
20A
F10
A
125V
25A
F10
A
125V
30A
F10
B
250V
1/10A
F10
B
125V
15/100A
F10
B
125V
2/10A
F10
B
125V
3/10A
F10
B
250V
4/10A
F10
B
250V
1/2A
F10
B
250V
6/10A
F10
B
250V
8/10A
F10
B
250V
1A
F10
B
250V
1 1/4A
F10
B
250V
2A
F10
B
250V
2 1/2A
F10
B
250V
3A
F10
B
250V
3 2/10A
F10
B
250V
4A
F10
B
250V
5A
F10
B
250V
5 6/10A
F10
B
250V
6 1/4A
F10
B
125V
7A
F10
B
125V
8A
F10
B
125V
10A
1/ For silver plated terminals, the designator "S" is added
after the current rating.
VERIFICATION:
Qualification inspection is not applicable for 12A and 25A characteristic A fuses and all characteristic B
fuses of this specification sheet (see table l) and shall be replaced by first article inspection consisting
of Group A and Group B inspections of MIL-PRF-15160, prior to delivery.
Qualification inspection (Characteristic A only): The number of qualification samples required shall be
a. 24 samples maximum current rating of each voltage and design.
b. 24 samples minimum current rating of each voltage and design.
NOTE: If labels are used, five additional samples of any rating are required.
