INCH-POUND
MIL-PRF-15160/16F
15 November 2011
SUPERSEDING
MIL-PRF-15160/16E
7 July 2006
PERFORMANCE SPECIFICATION SHEET
FUSES, INSTRUMENT, POWER, AND TELEPHONE
(NONINDICATING), STYLE F16
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein
shall consist of this specification sheet and MIL-PRF-15160.
Inches
mm
Ltr
Min
Max
Min
Max
A
2.969
3.031
75.41
76.99
B
.804
.820
20.42
20.83
C
.625
---
15.88
---
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
FIGURE 1. Style F16, characteristic A.
AMSC N/A
FSC 5920
