MIL-PRF-15160/16F
Part or Identifying Number (PIN): The PIN shall be constructed from table II (e.g., F16A250V35A, or
F16BR250V60A).
TABLE II Part or Identifying Number. 1/
Style
Characteristic
Maximum
Current rating
voltage
F16
A
250 V
35A
F16
A
250 V
40A
F16
A
250 V
45A
F16
A
250 V
50A
F16
A
250 V
60A
F16
BR
2/
250 V
35A
F16
BR
2/
250 V
40A
F16
BR
2/
250 V
45A
F16
BR
2/
250 V
50A
F16
BR
2/
250 V
60A
1/ For silver plated terminals, the designator "S" is added after the
current rating.
2/ The characteristic B fuse has been discontinued. The characteristic
BR fuse may be used to replace the old characteristic B fuse of the
same current rating.
VERIFICATION:
Qualification inspections: The number of qualification samples required shall be:
a. 24 samples maximum current rating of each voltage and design.
b. 24 samples minimum current rating of each voltage and design.
NOTE: If labels are used, five additional samples of any rating are required.
Referenced documents. In addition to MIL-PRF-15160, this document references the following:
The margins of this specification are marked with vertical lines to indicate where changes from the
previous issue were made. This was done as a convenience only and the Government assumes no
liability whatsoever for any inaccuracies in these notations. Bidders and contractors are cautioned to
evaluate the requirements of this document based on the entire content irrespective of the marginal
notations and relationship to the last previous issue.
4
