MIL-PRF-15160/40C
REQUIREMENTS:
Interface and physical dimensions: See figure 1.
Case material: Fiber or black paper.
Ferrule material: Brass.
Lug material: Brass.
Terminal strength (ferrules): 5 inch-pound torque.
Electrical:
Current rating: See table I.
Voltage rating: See table I.
Characteristic: See table I and table II.
Type designation: Type designation shall be as specified in table I.
TABLE I. Type designation.
Style
Characteristic
Voltage
Current
F40
A
32V
40A
F40
A
32V
50A
F40
A
32V
60A
F40
A
32V
70A
F40
A
32V
75A
F40
A
32V
80A
F40
A
32V
100A
F40
A
32V
125A
F40
A
32V
150A
F40
B
32V
40A
F40
B
32V
50A
F40
B
32V
60A
F40
B
32V
70A
F40
B
32V
75A
F40
B
32V
80A
F40
B
32V
100A
F40
B
32V
125A
F40
B
32V
150A
Overload interrupt: See table II.
Short circuit interrupt: 10,000 A at rated voltage dc.
Insulation resistance: 0.1 megohm minimum.
