MIL-PRF-15160/60J
INSPECTION ROUTINE:
AC short circuit test: AC short circuit tests shall be performed at the currents shown in table II at not
less
than 500 volts, single phase, and not greater than 20 percent power factor, lagging. The current shall
be
applied within plus or minus 10 degrees of the zero point of the voltage wave.
DC short circuit test: DC short circuit tests shall be performed at the currents shown in table II at not
less than 500 volts. The rate of rise shall be between 25,000,000 and 30,000,000 amperes per second.
Cross-reference: For applicable cross-reference see table III. The existing stocks of superseded items
may be used. When exhausted, the superseding parts shall be used.
TABLE III. Cross-reference.
Superseding
Superseded numbers for CAGE
number
81349
96906
---
---
F60C500V1/8A
---
---
F60C500V1/4A
---
---
F60C500V3/8A
---
---
F60C500V1/2A
---
---
F60C500V3/4A
MS15249-1
F60H1R00C
F60C500V1A
MS15249-3
F60H3R00C
F60C500V3A
MS15249-5
F60H5R00C
F60C500V5A
MS15249-6
F60H6R00C
F60C500V6A
MS15249-8
F60H8R00C
F60C500V8A
MS15249-10
F60H10R0C
F60C500V10A
MS15249-15
F60H15R0C
F60C500V15A
MS15249-20
F60H20R0C
F60C500V20A
MS15249-25
F60H25R0C
F60C500V25A
MS15249-30
F60H30R0C
F60C500V30A
Referenced documents. In addition to MIL-PRF-15160, this document references the following:
The margins of this specification sheet are marked with vertical lines to indicate where changes from the
previous issue were made. This was done as a convenience only and the Government assumes no
liability whatsoever for any inaccuracies in these notations. Bidders and contractors are cautioned to
evaluate the requirements of this document based on the entire content irrespective of the marginal
notations and relationship to the last previous issue.
