INCH-POUND
MIL-PRF-19207/21M
9 January 2014
SUPERSEDING
MIL-F-19207/21L
24 April 2007
PERFORMANCE SPECIFICATION SHEET
FUSEHOLDERS, EXTRACTOR POST TYPE, BLOWN FUSE INDICATING,
NON-EMI/RFI SHIELDED AND EMI/RFI SHIELDED,
TYPE FHL32W AND TYPE FHL32WS
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein
shall consist of this specification sheet and MIL-PRF-19207.
Ltr
Inches
mm
Ltr
Inches
mm
Min
Max
Min
Max
Min
Max
Min
Max
A
1.100
1.140
27.94
28.96
G
---
.440
---
11.18
B
.980
1.020
24.89
25.91
H
.560 (REF)
14.22 (REF)
C
.540
.580
13.72
14.73
J
.055
.065
1.40
1.65
D
.700 (REF)
17.78 (REF)
K
.820
.825
20.83
20.96
E
.940 (REF)
23.88 (REF)
L
.882
.887
22.40
22.53
F
---
1.090
---
27.69
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerances are ±0.02 (0.51 mm) for two-place decimals and ±0.005
(0.13 mm) for three-place decimals.
4. The location (on the fuseholder body) of the manufacturer's identification and electrical rating is
optional.
FIGURE 1. Type FHL32W fuseholder.
AMSC N/A
FSC 5920
