MIL-PRF-19207/38E
Ltr
Inches
mm
Ltr
Inches
mm
Min
Max
Min
Max
Min
Max
Min
Max
A
1.171
1.203
29.74
30.56
P
.511
.521
12.98
13.23
B
.495
.505
12.57
12.83
R
.253
.263
6.43
6.68
C
1.796
1.828
45.62
46.43
S
.200
.210
5.08
5.33
E
.090
.100
2.29
2.54
T
.104
.114
2.64
2.90
F
.850
.860
21.59
21.84
U
.151
.161
3.84
4.09
G
.950
.960
24.13
24.38
V
.933
.943
23.70
23.95
H
.573
.583
14.55
14.81
W
.464
.474
11.79
12.04
J
.185
.195
4.70
4.95
X
.870
.880
22.10
22.35
K
.830 (REF)
Y
.395
.405
10.03
10.29
L
---
3.875
---
98.43
Z
.795
.805
20.19
20.45
M
.370
.380
9.34
9.65
AA
1.677 (REF)
42.60 (REF)
N
.969
.979
24.61
24.87
AB
.040
.080
1.02
2.03
FIGURE 1. Type FHL57G fuseholder - contined.
Letter V indicated in the dimensional table corresponds to the "U" contact dimension.
Ltr
Inches
mm
Ltr
Inches
mm
Min
Max
Min
Max
Min
Max
Min
Max
A
1.177
1.197
29.90
30.40
L
.695
.705
17.65
17.91
B
.950
.960
24.13
24.38
M
.590
.630
14.99
16.00
C
.933
.943
23.70
23.95
N
.140
.160
3.56
4.06
E
.435
.445
11.05
11.30
P
.385
.425
9.78
10.80
F
.188
.198
4.78
5.03
R
.150
.200
3.81
5.08
G
.850
.860
21.59
21.84
S
2.140
2.240
54.36
56.90
H
.365
.375
9.27
9.53
T
2.305
2.355
58.55
59.82
J
.310
.320
7.87
8.13
V
.385
.395
9.78
10.03
K
1.802
1.822
45.77
46.28
See notes at end of figures.
FIGURE 2. Body for FHL57G fuseholders.
