MIL-PRF-19207/7N
Ltr
Inches
mm
Ltr
Inches
mm
Min
Max
Min
Max
Min
Max
Min
Max
A
4.380 (REF)
111.25 (REF)
M
.245
.255
6.22
6.48
B
.091
.101
2.311
2.565
N
8.19 (REF)
208.03 (REF)
C
1.820 (REF)
46.23 (REF)
P
4.25 (REF)
107.95 (REF)
D
1.250 (REF)
31.75 (REF)
R
1.75 (REF)
38.10 (REF)
E
3.920
3.960
99.57
100.58
S
1.63 (REF)
41.40 (REF)
F
.055
.065
1.40
1.65
T
2.42
2.46
61.47
62.48
G
1.630 (REF)
41.40 (REF)
U
1.23
1.27
31.24
32.26
H
3.670
3.710
93.22
94.23
V
.339
.349
8.61
8.86
J
3.170
3.210
80.52
81.53
W
1.808
1.818
45.92
46.18
K
2.13 (REF)
54.10 (REF)
X
1.307
1.317
33.20
33.45
L
.245
.255
6.22
6.48
Y
2.933
2.943
74.50
74.75
NOTES:
1. Dimensions are in inches.
2. Unless otherwise specified, tolerances are ± .005 (0.13 mm) for three placed decimals and ± .02 (0.51 mm) for
two place decimals.
3. Metric equivalents are given for general information only.
4. Cap and body molding material: It is suggested that type MAI-60, GDI-30F or SDG-F of American Society for
Testing and Materials ASTM-D5948 be considered for meeting the cap and body molding material requirements
of this specification. ASTM-D3935 is also suggested as guidance for cap material.
FIGURE 1. Type FHL16G fuseholder - Continued.
