MIL-PRF-23419/1L
Qualification and group C inspection:
Inspection routine. The number of group II samples for qualification and subgroup 2 samples for
group C inspection shall be as shown in table II.
TABLE II. Group II and subgroup 2 samples.
Inspection
Number of sample fuses
Group II and subgroup 2
16
Terminal strength
4
Overload interrupt
200 percent at -55°C
4
200 percent at +85°C
4
300 percent at -55°C
4
300 percent at +85°C
4
The number of group III samples for qualification ( or first article ) and subgroup 1 for group C
testing shall consist of the number of sample units shown in table III. Short circuit interrupt tests
shall be conducted at the voltage indicated, and the fuses shall be capable of withstanding a
minimum short circuit current as shown in table III.
TABLE III. Sampling for short circuit qualification and group C tests.
Current rating
Short circuit current (amps)
Number of sample
(amps)
units
28 Volts
125 Volts
AC
DC
AC
1/200
3000
60
12
1/10
3000
12
1/8
1500
12
5
1500
60
12
4
