MIL-PRF-23419/10C
Qualification and group C inspection:
Inspection routine: The number of group II samples for qualification, and subgroup 2 samples for
group C inspection, shall be as shown in table II.
TABLE II. Group II and subgroup 2 samples.
Number of
Inspection
sample fuses
Group II and subgroup 2
16
Terminal strength
4
Overload interrupt
200% at -55° C
4
200% at +125° C
4
300% at -55° C
4
300% at +125° C
4
The number of group III samples for qualification (or first article) and subgroup 1 for group C
inspection, shall consist of four sample fuses of each of the current ratings as shown in table III.
Short circuit interrupt tests shall be conducted at the direct current voltage indicated, and the fuses
shall be capable of withstanding a minimum short circuit current as shown in table III.
TABLE III. Short circuit tests.
Fuse style
Current rating
Short circuit
Voltage
Short circuit
current (dc)
current (ac)
FM10
10A
300A
125V
50A
FM10
15A
300A
32V
50A
Referenced documents. In addition to MIL-PRF-23419, this document references the following:
The margins of this specification are marked with vertical lines to indicate where changes from the
previous issue were made. This was done as a convenience only and the Government assumes no
liability whatsoever for any inaccuracies in these notations. Bidders and contractors are cautioned to
evaluate the requirements of this document based on the entire content irrespective of the marginal
notations and relationship to the last previous issue.
4
