MIL-PRF-19207/16J
REQUIREMENTS
Cap and body molding material: Molding materials shall be selected to enable the fuseholder to meet the
performance requirements of this specification. It is recommended that types MAI-60, GDI-30F or SDG-F of
American Society for Testing and Materials ASTM-D5948 be considered for meeting the cap and body
molding material requirements of this specification.
Gaskets and O-rings: It is recommended that class 3 silicone rubber of A-A-59588 (Rubber, Silicone), be
considered for use in meeting the gasket and o-ring material requirements of this specification.
Fuse accommodation:
Ferrule type:
Size: 0.250 inch (6.35 mm) diameter, 1.250 inches (31.75 mm) length.
(or equivalent size and style)
Poles: One.
Rating: 30 amperes, 250 volts maximum.
Panel thickness: 0.187 inch (4.76 mm) maximum.
Nonindicating.
Lamp series resistor: None.
Terminals: Solder lug type.
Enclosure:
FHN26G1 and FHN26G2 - Dripproof.
FHN26W - Watertight.
Test fuses:
Temperature rise: F03A125V30A of MIL-PRF-15160/3.
Short circuit:
F03A250V15A of MIL-PRF-15160/3.
Mechanical shock: Method I of MIL-PRF-19207.
Terminal strength: 5 pounds.
Torque: Mounting - 20 inch-pounds for FHN26G1 and FHN26G2; 30 inch-pounds for FHN26W.
Salt spray (corrosion): Test condition B.
Part or Identifying Number (PIN): See table I.
TABLE I.
Superseding PIN
Superseded military
part number
FHN26G1
M19207/16-001
FHN26G2
M19207/16-002
FHN26W
M19207/16-003
4
