MIL-PRF-19207/20F
Ltr
Inches
mm
Ltr
Inches
mm
Min
Max
Min
Max
Min
Max
Min
Max
H
.500
.510
12.70
12.95
N
.442
.450
11.23
11.43
J
.468
.478
11.89
12.14
P
.100
---
2.54
---
K
.166
.176
4.22
4.47
R
.589
.599
14.97
15.21
L
2.22
2.26
56.39
57.40
S
.603
.693
15.32
17.60
M
.714
.724
18.14
18.39
NOTES:
1. Dimensions are in inches.
2. Metric equivalents (to the nearest .01 mm) are given for general information only and are based
upon 1 inch = 25.4 mm.
3. Unless otherwise specified, tolerances are ±.02 (0.51 mm) for two-place decimals and ±.005 (0.13 mm)
for three-place decimals.
4. Formerly type FHN31G.
FIGURE 2. Type FHN31G2.
2
