MIL-PRF-19207/9L
Ltr
Inches
mm
Ltr
Inches
mm
Min
Max
Min
Max
Min
Max
Min
Max
A
.280
.340
7.11
8.64
J
.090
.130
2.29
3.30
B
.480
.520
12.19
13.21
K
.070
.110
1.78
2.79
C
.920
.960
23.37
24.38
L
.100
.140
2.54
3.56
D
.920
.960
23.37
24.38
M
.035
.045
.89
1.14
E
.025
.035
.64
.89
N
.790
.830
20.07
21.08
F
.820
.860
20.83
21.84
P
.510
.520
12.95
13.21
G
.420
.460
10.67
11.68
R
.570
.575
14.48
14.61
H
---
2.38
---
60.45
S
.625
.635
15.88
16.13
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerances are ±.005 (0.13 mm) for three place decimals and ±.02
(0.5 mm) for two place decimals.
FIGURE 2. Type FHL18G2.
