MIL-PRF-19207/9L
REQUIREMENTS:
Body molding material: It is suggested that type MAI-60, GDI-30F or SDG-F of American Society for
Testing and Materials ASTM-D5948 be considered for meeting the body molding material requirements of
this specification.
Fuse accommodation:
Ferrule type:
Size: .250 inch (6.35 mm) diameter, 1.250 inches (31.75 mm) length.
Poles: One.
Ratings: 20 amperes (see table I for voltage).
Panel thickness: 0.187 inch (4.76 mm) maximum.
Indicating: Incandescent lamp with amber color cap (see table I).
Gaskets and O-rings: Gaskets and O-rings shall be used that enable the fuseholder to meet the
performance requirements of this specification. It is suggested that gaskets which meet class 3
of A-A-59588 be considered for use.
Lamp series resistor: See table I.
Part or Identifying Number (PIN): FHL18G1 or FHL18G2, depending on type, along with a dash
number from table l.
TABLE I. Voltage, lamp and series resistor.
Dash
Voltage rating
Lamp number
Resistance
Resistor type
Resistor
number
1/
(ohms)
specification
-01
12-22
1764 or 1762X
Shorting wire
N/A
N/A
-02
23-33
1764 or 1762X
330
RLR-20 2/
-03
34-45
1764 or 1762X
681
RWR-80 3/
-04
46-60
1764 or 1762X
1,210
RWR-80 3/
-05
61-80
1764 or 1762X
1,870
RWR-89 3/
-06
81-90
1764 or 1762X
2,050
RWR-89 3/
-07
2.5-4
1784
Shorting wire
N/A
N/A
-08
5-7
1784
22.1
RWR-80 3/
-09
8-12
1784
39.2
RWR-80 3/
1/ Industry number.
2/ MIL-PRF-39017, type RLR resistors may be used in lieu of RCR types. This is a recommended
replacement, not a direct substitute.
3/ MIL-PRF-39017, type RLR resistors may be used as possible replacements in lieu of RWR types.
This is a recommended replacement, not a direct substitute.
3
