MIL-PRF-23419/2R
The number of group III samples for qualification, and subgroup 1 for group C inspection, shall consist of
four fuses of each of the styles shown in table III. Short circuit interrupt tests shall be conducted at the
alternating current voltage indicated, and the fuses shall be capable of withstanding a minimum short
circuit current as shown in table III.
TABLE III. Short circuit tests.
Fuse style
Current rating
Short circuit current
AC type voltage
FM02
2A
10,000 A
125 V
FM02
5A
300 A
125 V
Supersession and cross reference: The superseding items include the requirements of the superseded
items. The existing stocks of superseded items may be used. When exhausted, the superseding items
shall be used ( see table IV ).
TABLE IV. Cross-reference.
Superseding PIN
Superseded numbers
FSCM 81349
FSCM 81349
FSCM 81349
FSCM 81349
FSCM 81349
FSCM 81349
FM02A125V1/500A
FM02-125V 1/500A
FM02-1/500A
FM02125V1/500A
FM021/500A
M23419/2-001
FM02A125V1/200A
FM02-125V 1/200A
FM02-1/200A
FM02125V1/200A
FM021/200A
M23419/2-002
FM02A125V1/100A
FM02-125V 1/100A
FM02-1/100A
FM02125V1/100A
FM021/100A
M23419/2-003
FM02A125V1/64A
FM02-125V 1/64A
FM02-1/64A
FM02125V1/64A
FM021/64A
M23419/2-004
FM02A125V1/32A
FM02-125V 1/32A
FM02-1/32A
FM02125V1/32A
FM021/32A
M23419/2-005
FM02A125V1/16A
FM02-125V 1/16A
FM02-1/16A
FM02125V1/16A
FM021/16A
M23419/2-006
FM02A125V1/10A
FM02-125V 1/10A
FM02-1/10A
FM02125V1/10A
FM021/10A
M23419/2-007
FM02A125V1/8A
FM02-125V 1/8A
FM02-1/8A
FM02125V1/8A
FM021/8A
M23419/2-008
FM02A125V2/10A
FM02-125V 2/10A
FM02-2/10A
FM02125V2/10A
FM022/10A
M23419/2-009
FM02A125V1/4A
FM02-125V 1/4A
FM02-1/4A
FM02125V1/4A
FM021/4A
M23419/2-010
FM02A125V3/10A
FM02-125V 3/10A
FM02- 3/10A
FM02125V3/10A
FM02 3/10A
M23419/2-011
FM02A125V4/10A
FM02-125V 4/10A
FM02-4/10A
FM02125V4/10A
FM024/10A
M23419/2-012
FM02A125V1/2A
FM02-125V 1/2A
FM02-1/2A
FM02125V1/2A
FM021/2A
M23419/2-013
FM02A125V6/10A
FM02-125V 6/10A
FM02-6/10A
FM02125V6/10A
FM026/10A
M23419/2-014
FM02A125V3/4A
FM02-125V 3/4A
FM02-3/4A
FM02125V3/4A
FM023/4A
M23419/2-015
FM02A125V1A
FM02-125V 1A
FM02-1A
FM02125V1A
FM021A
M23419/2-016
FM02A125V1-1/2A
FM02-125V 1-1/2A
FM02-1-1/2A
FM02125V1-1/2A
FM021-1/2A
M23419/2-017
FM02A125V2A
FM02-125V 2A
FM02-2A
FM02125V2A
FM022A
M23419/2-018
FM02A125V3A
FM02-125V 3A
FM02-3A
FM02125V3A
FM023A
M23419/2-019
FM02A125V4A
FM02-125V 4A
FM02-4A
FM02125V4A
FM024A
M23419/2-020
FM02A125V5A
FM02-125V 5A
FM02-5A
FM02125V5A
FM025A
M23419/2-021
4
