MIL-DTL-24646-2 Fuse Boxes, Feeder Distribution, Totally Enclosed, 125/250 Volts, Direct Current, Three Wire Buses, Two Wire Branches, 0-30 Ampere Midget Fuses, Symbols 609,610 And 611

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8


MIL-DTL-24646/2B
A. Symbols 609, and 610
B. Symbol 611
SYMBOL
DIMENSIONS
NO
A
B
609
5.00
10.00
610
6.50
13.00
FIGURE 3. Mounting dimensions, ref.
3
