MIL-DTL-24646/2B
REQUIREMENTS
Symbol numbers: See table I.
Design:
Electrical rating: 125/250 volts direct current, 0-30 ampere.
Dimensions and configuration: See figures 1, 2, 3 and 4.
Wiring diagrams: See figure 5.
Mounting dimensions: See figure 3.
Degree of enclosure: Totally enclosed.
Designation and marking: See MIL-DTL-24646.
Parts: The parts listed in table II and specified in MIL-DTL-24646 shall be used in the construction
of the fuse boxes specified herein.
General information:
Military part numbers and general information are as specified in table I.
TABLE I. Military part numbers and general information.
Supersedes
Weight
Military
Symbol
No. of
Feeder
Branch
Fuse
Bus bar
in
no.
part no.
circuits
MCM
MCM
size
size
Type
Drawing
pounds
no.
M24646/2-
609
19.0
4
75
14
midget
0.62 x 0.19
9000-S-
LL-S
001
0-30A
6202-73160
M24646/2-
610
24.6
8
75
14
midget
0.62 x 0.19
9000-S-
NN-S
002
0-30A
6202-73162
M24646/2-
611
29.4
12
75
14
midget
0.62 x 0.19
9000-S-
PP-S
003
0-30A
6202-73163
6
