MIL-PRF-19207G
TABLE I. Qualification inspection.
Requirements
Test method
Examination or test
Group I - All samples
Visual and mechanical examination
Indicating lamp (characteristic L) as for group A tests
Insulation resistance
Contact resistance
Enclosure (sealed types only)
Group II - Two samples
Thermal shock
Terminal strength
Moisture resistance
Salt spray (corrosion)
Dielectric withstanding voltage
Group III - Two samples
Solderability
Overload
Temperature rise
Endurance
Dielectric withstanding voltage
Group IV - Two samples
Vibration
Mechanical shock
Indicating lamp
Dielectric withstanding voltage (see 3.1)
RFI/EMI Shielding (when specified in 3.1)
Group V - Two samples
Torque strength of inserts, threaded terminals, and
molded threads
Dielectric withstanding voltage
Group VI - Two samples
Short circuit
Dielectric withstanding voltage
4.4.1 Samples for qualification. Samples submitted for qualification approval shall be representative
of the contractor s normal production and shall be taken, preferably, from a current production lot. Ten
specimens of each type for which approval is requested shall be submitted for qualification approval.
However, when a contractor s design for a particular type is basically the same in various current or
voltage ratings, one set of specimens may be submitted for approval of that design. For this case,
approval shall be extended to all units submitted by the same contractor of the same design of lower
current or voltage rating. Qualification approval of a type listed in column I of table II shall be extended to
the type shown opposite in column II except for visual and mechanical examination and the tests listed in
column III. Two samples of each fuseholder listed in column II shall be submitted for visual and
mechanical examination. Samples for tests listed in column III shall be tested as specified in the
applicable group in table I.
